GENE SLOVERS
US NAVY PAGES

A. A. RANGE TABLE
FOR
16-INCH 50-CALIBER GUN
HOME                INDEX
                                                                          CONTENTS

PART I                                                                                                                              Page

Explanatory notes                                                                                                                   1
Elements of trajectories versus time of flight and elevation                                                          3
Sight angle versus 8lant range and position angle                                                                        16
Time of flight versus slant range and position angle                                                                    18

PART II

Drift versus time of flight and elevation                                                                                      20
Drift versus slant range and position angle                                                                                  21
Deflection for cross wind versus time of flight and elevation                                                        23
Deflection for cross wind versus slant range and position angle                                                    24

PART III

Effect on horizontal range and altitude due to:
Change in initial velocity                                                                                                            26
Change in air density                                                                                                                 28
Change in elevation                                                                                                                   30
Rear wind                                                                                                                                32

PART IV

Corrections to sight angle and time of flight for:
Change in initial velocity                                                                                                              34
Change in air density                                                                                                                   36
Change in projectile weight                                                                                                          38
Rear wind                                                                                                                                  40

GRAPHICAL DATA
Trajectory Sheet inside back cover
